Designed by Tappers for Tappers
• This machine has 46” of travel and performs taps 12” – 24”.
• - Travel can be increased if desired to 60” with “T46-60 Rail and Boring-bar” package.
• - Very Powerful Built in drive unit
• - Tapping machine is hydraulic driven: 16 gallons at 2000 psi. is preferred.
• - Machine has patented “Selectable-feed” 1 – speed for advancing and 1 speed – for cutting.
• - 3” Boring Bar for ridged cutting.
• - Gear driven for precision cutting and dependability
• - Dual Hydraulic motor drive for non-stop cutting
• - Mueller style cutters bolt up with use of an adapter
• - 285 psi. working pressure with quoted adaptors.
• - 285psi & 250 degrees (F) with provided packing, Higher Temperatures are available with optional packing.
• American std & British std, adaptors
Operating max. pressure 285 psi. @ 100° F
Operating temperature 250° F @ 200 psi.
